ESAB Fabricator ES 410iC CE Arc Welder Power Source - 400v, 3ph
0447100881

Name: ESAB Fabricator ES 410iC CE Arc Welder Power Source - 400v, 3ph
SKU: 0447100881
Price: 1699.00 GBP

£1699.00 EX VAT

SSP Suggested Selling Price = £2432.77 YOU SAVE £733.77

Buy in 3 easy interest free payments of £566.33^† with

Additional items to consider

Please note, this product does not qualify for our standard shipping rates outside of the UK Mainland. Please contact us for shipping rates for this product.

The Fabricator ES 410iC is a heavy-duty inverter-controlled power source for MMA (Stick) welding, TIG (live-TIG) welding and CC Carbon-Air Arc Gouging. The Fabricator ES 410iC is built to withstand rugged use making it a perfect solution for industrial usage. Ideal for heavy industries using all types of electrodes, including Cellulosic.

Features

The intuitive control panel of the ES 410iC makes it easy to optimise settings, reducing the time taken to achieve the best weld characteristics
Equipped with Hot Start and Arc Force with the possibility to adjust parameters during welding. Hot Start helps to avoid starting problems while Arc Force sets the intensity of the arc for improved weld quality
Built-in Anti-Stick function to prevent the electrode from getting accidentally stuck in the puddle
Wide mains voltage tolerance allows for stable welding
Easy to read and quick to set panel increasing the accuracy and reducing the downtime
Inverter controlled for high efficiency and low power consumption
Excellent welding performance with all types of electrodes including Cellulosic

Product Details

Specifications

Mains Voltage: 380-400-415-440 VAC (-15% +10%), 3 Ph,50/60 Hz
Fuse Slow: 32 A
Welding Output: 400 A at 60% Duty Cycle, at 40°C, 310 A at 100% Duty Cycle, at 40°C
Setting Range MMA/TIG: 30 –410 A / 10 –410 A
Efficiency Max Current: 89% MMA and 86% TIG
Idle Power Consumption: 40 W (VRD OFF) 15 W (VRD ON)
Maximum Open Circuit Voltage (Max. With VRD ON): 76 VDC (15VDC)
Enclosure Class, CE / non-CE: IP23S
Operating Temperature: -10 to +40°C (+14 to +104°F)
Certification Mark (Standard): CE
Dimensions LxWxH: 525 ×280 ×475 mm
Weight: 35.2Kg
